Thông tin chi tiết sản phẩm:
|
| Áp lực làm việc tối đa: | 7Bar | Tốc độ dòng chảy tối đa: | 36lpm |
|---|---|---|---|
| Tốc độ chuyển đổi tối đa: | 400cpm | Chiều cao hút tối đa: | 3,5m |
| Lượng ngũ cốc tối đa được phép: | 2,5mm | Tiêu thụ không khí tối đa: | 8,510l/s |
| kích thước đầu vào không khí: | 1/4 trong | Kích thước cửa thoát khí: | 3/8 trong |
| Kích thước ổ cắm chất lỏng: | 1/2 3/4 in | kích thước ổ cắm chất lỏng: | 1/2 3/4 in |
| Cân nặng: | 16kg | Vật liệu cơ hoành: | PTFE |
| Chất liệu thân bơm: | Nhôm | Kích thước đầu ra: | 1/2 |
| Nguồn điện: | Khí nén | ||
| Làm nổi bật: | RV PTFE diaphragm pump 36lpm,pneumatic diaphragm pump 100psi,PTFE diaphragm pump high flow |
||
| Attribute | Value |
|---|---|
| Warranty | 1 year |
| Customized Support | OEM, ODM |
| Power Source | Pneumatic |
| Structure | Diaphragm Pump |
| Outlet Size | 1/2 |
| Material | PTFE |
| Color | Black |
| Weight | 16kgs |
| Diaphragm | PTFE |
| Brand | RV |
| Packing | Carton |
| Max Pressure | 100psi (0.7Mpa, 7bar) |
| Pump Body | Aluminum |
| Max Flow | 36lpm |
| Max Working Pressure | 7bar |
| Max Flow Rate | 36lpm |
| Max Reciprocating Speed | 400cpm |
| Max Suction Height (Dry Sucking) | 3.5m |
| Max Permitted Grain | 2.5mm |
| Max Air Consumption | 8.510L/S |
| Air Inlet Size | 1/4 in |
| Air Outlet Size | 3/8 in |
| Fluid Inlet Size | 1/2 3/4 in |
| Fluid Outlet Size | 1/2 3/4 in |
| Weight | PTFE pump 16 kg |
Jiangliang Technology Co., Ltd is headquartered in Shanyang Town, Jinshan District of Shanghai, with 2 production bases and 3 branches in the mainland of China.
Shanghai Jianglang has been awarded as High-Tech Enterprise and Credit Company title in consecutive years. We have strong capability of design, innovation, precision production and tight cooperation with Shanghai universities.
Our main products are diaphragm pumps and control valves, including: Pneumatic Diaphragm Pump, Electric Diaphragm Pump, Piston Pump, Powder Pump, Sanitary Pump, Diaphragm Pump with Leakage Detector Controller, Pneumatic Diaphragm Regulating Valve, Control Valve, Sequencing Valve and related products.
The pumps and valves have been granted more than 40 patents, including 10 invention patents. Jianglang participated in setting norms and standards for technical specification for pneumatic diaphragm pumps in petrochemical industry.
