Thông tin chi tiết sản phẩm:
|
| Áp lực tối đa: | 120psi (0,84MPa, 8.4bar) | Dòng chảy tối đa: | 150gpm (570lpm) |
|---|---|---|---|
| Tốc độ dòng chảy tối đa: | 40GPM (150lpm) | Tốc độ chuyển đổi tối đa: | 276cpm |
| Chiều cao hút tối đa: | 5m | Lượng ngũ cốc tối đa được phép: | 0,16 in (4mm) |
| Tiêu thụ không khí tối đa: | 45scfm ((22,5L/s) | kích thước đầu vào không khí: | 1/2in |
| Kích thước cửa thoát khí: | 3/4 in | Kích thước ổ cắm chất lỏng: | 1 TRONG |
| kích thước ổ cắm chất lỏng: | 1 trong | trọng lượng máy bơm: | 34KGS |
| Vật liệu: | thuế TTĐB | Vật liệu cơ hoành: | PTFE |
| Nguồn điện: | Khí nén | ||
| Làm nổi bật: | 120psi Max Pressure AODD Pump,150gpm Max Flow AODD Pump,1 Year Warranty AODD Pump |
||
| Parameter | Value |
|---|---|
| Max Working Pressure | 120 psi (0.84Mpa, 8.4bar) |
| Max Flow Rate | 40gpm (150lpm) |
| Max Reciprocating Speed | 276cpm |
| Max Suction Height (Dry Sucking) | 5m |
| Max Permitted Grain | 0.16 in (4mm) |
| Max Air Consumption | 45scfm (22.5L/S) |
| Air Inlet Size | 1/2in |
| Air Outlet Size | 3/4in |
| Fluid Inlet Size | 1in |
| Fluid Outlet Size | 1in |
| Weight | 34KGS |
Jiangliang Technology Co.,Ltd is headquartered in Shanyang Town, Jinshan District of Shanghai, with 2 production bases and 3 branches in the mainland of China.
Shanghai Jianglang has been awarded as High-Tech Enterprise and Credit Company title in consecutive years.
We have strong capability of design, innovation, precision production and tight cooperation with Shanghai universities. Our main products are diaphragm pumps and control valves, including:
The pumps and valves have been granted more than 40 patents, including 10 invention patents. Shanghai Jianglang participated in setting norms and standards for technical specification for pneumatic diaphragm pumps in petrochemical industry, according to the national standard No.: SH/T 3191-2017.
We hold necessary certificates such as TS.A National Manufacturing License, CE, ATex, ISO9001, SGS and more.
We serve various industries including chemical, painting & coating, water treatment, petroleum, environmental protection, and food/pharmaceutical industries.
We have established long term business relationships with famous enterprises such as BASF, Bayer, and SAMSUNG. Our RV pneumatic diaphragm pump has been exported to more than 70 countries and regions.
Our engineers will select the most suitable and economical material according to your specific working conditions:
