Thông tin chi tiết sản phẩm:
|
| Áp lực đầu ra tối đa: | 0,6MPa, 6bar | Tốc độ dòng chảy tối đa: | 6m³/giờ |
|---|---|---|---|
| Lực hút tối đa: | 3M | Công suất động cơ: | 2.2KW (tiêu chuẩn), 3.0KW (tùy chọn) |
| Tốc độ động cơ: | 1450 vòng/phút | Kích thước ổ cắm chất lỏng: | 1 1/2 inch |
| kích thước ổ cắm chất lỏng: | 1 1/2 inch | Cân nặng: | 122 KGS (Thép không gỉ) |
| Vật liệu bơm: | thép không gỉ | Loại động cơ: | Chống nổ |
| Nguồn điện: | Điện | Cấu trúc bơm: | Bơm màng |
| Loại kết nối: | ren hoặc mặt bích | Vật liệu cơ hoành: | Teflon, Santoprene, Viton, Hytrel, Buna-N |
| Vật liệu phụ tùng ướt: | PP, PVDF, Acetal, hợp kim nhôm, sắt dẻo, thép không gỉ | ||
| Làm nổi bật: | 6m³/h Flow Rate Electric Diaphragm Pump,1 Year Warranty Diaphragm Pump,Transport Liquid Stainless Steel Pump |
||
| Specification | Value |
|---|---|
| Max Outlet Pressure | 0.6Mpa, 6bar |
| Max Flow Rate | 6m³/h |
| Max Suction Lift | 3m |
| Motor Power | 2.2KW standard (3.0KW optional) |
| Motor Speed | 1450r/min |
| Fluid Inlet Size | 1 1/2 inch Threaded or Flange |
| Fluid Outlet Size | 1 1/2 inch Threaded or Flange |
| Weight | Stainless steel pump: 122 KGS Aluminum pump: 77KGS Carbon steel pump: 115KGS |
Shanghai Jiangliang Technology Co.,Ltd is headquartered in Shanyang Town, Jinshan District of Shanghai, with 2 production bases and 3 branches in mainland China. We have been awarded as High-Tech Enterprise and Credit Company in consecutive years.
Our capabilities include design, innovation, precision production, and cooperation with Shanghai universities. Our product line includes diaphragm pumps and control valves: Pneumatic Diaphragm Pump, Electric Diaphragm Pump, Piston Pump, Powder Pump, Sanitary Pump, Diaphragm Pump with Leakage Detector Controller, Pneumatic Diaphragm Regulating Valve, Control Valve, and Sequencing Valve.
Our pumps and valves hold more than 40 patents, including 10 invention patents. We participated in setting technical specifications for pneumatic diaphragm pumps in the petrochemical industry (National Standard No.: SH/T 3191-2017). Certifications include TS.A National Manufacturing License, CE, ATex, ISO9001, and SGS.
We serve chemical, painting & coating, water treatment, petroleum, environmental protection, and food/pharmaceutical industries. Our clients include BASF, Bayer, and SAMSUNG, with exports to over 70 countries.
